OPERATING INSTRUCTIONS & PARTS MANUAL

16" REVERSIBLE WINDOW FAN
16" (40,64 cm)

Model

2EJR6G/9155G

Motor ...................................................................... 120V, 60 Hz
Blade size .............................................................. 16" (40,6 cm)
Speeds ................................................................... 3 intake, 3 exhaust
Control ................................................................... Rotary switch
Approvals ................................ ETL Listed. Close mesh fan guard
meets OSHA requirements.

Specifications

Description

The Air King® window fan features three intake and three exhaust
speeds and fits windows 26 1/2" (67,3 cm) to 34 1/2" (87,6 cm) wide
to 22" (55,9 cm) high. The adjustable side panels are designed to
accommodate fan mounting either inside or outside interior window
trim. The 16" (40,64 cm), 3-paddle fan blade is driven by a perma-
nently prelubricated motor, 6 foot (1,8 m), 18/3 cord set.

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF

AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY

AND/OR PROPERTY DAMAGE! RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

Rev. E 2/08

1

2082048A

GENERAL SAFETY INFORMATION

When using electrical appliances, basic precautions

should always be followed to reduce the risk of fire, electric

shock and injury to person, including the following:

1. Read all instructions before using Fan.

2. Make certain that the room is equipped with a working smoke detector.

3. Use this Fan only as described in this manual. Any other use not

recommended by the manufacturer may cause fire, electrical shock,

or injury to persons.

4. To reduce the risk of personal injury and electric shock, the Fan

should not be played with or placed where small children can reach it.

WARNING: DO NOT DEPEND UPON THE ON-OFF SWITCH AS

THE SOLE MEANS OF DISCONNECTING POWER WHEN INSTALL

ING OR SERVICING THE FAN. ALWAYS UNPLUG THE POWER

CORD.

5. Unplug power cord before installing, servicing, or moving the

Fan.

6. This Fan must NOT be used in potentially dangerous locations such

as flammable, explosive, chemical-laden or wet atmospheres where

gasoline, paint or flammable liquids are used or stored.

7. The power cord is equipped with a three-prong grounded plug

that must be inserted into a matching receptacle. Under no

circumstances must the grounding prong be cut off the plug.

Where a two-prong wall receptacle is encountered, it must be replaced

with a properly grounded three-prong receptacle installed in

accordance with the National Electrical Code (NEC) and all

applicable local codes and ordinances. This work must be done

only by a qualified electrician, using copper wire only.

WARNING: USE OF A THREE-PRONG TO TWO-PRONG ADAPTER

IS NOT RECOMMENDED. IMPROPER CONNECTION MAY CREATE

THE RISK OF ELECTROCUTION. USE OF SUCH ADAPTERS IS NOT

PERMITTED IN CANADA.

WARNING: THIS PLUG IS A SAFETY FEATURE. TO REDUCE THE

RISK OF FIRE, ELECTRIC SHOCK AND PERSONAL INJURY, DO NOT

REMOVE, REPLACE, REPAIR OR TAMPER WITH THE ORIGINALLY

SUPPLIED PLUG. IF THE FAN DOES NOT FUNCTION PROPERLY,

IT MAY BE DUE TO THE SAFETY DEVICE INCORPORATED IN THIS

PLUG.

8. This Fan is rated for use as a Window Fan, however, we recommend

that during rain, this Fan be removed from the window.

9. Where possible, avoid the use of extension cords. If they must be

used, minimize the risk of overheating by ensuring that they are

UL listed. NEVER use a single extension cord to operate more

than one Fan.

10. DO NOT operate any Fan with a damaged cord or plug or after the

Fan malfunctions, has been dropped or damaged in any manner.

Return Fan to authorized service facility for examination, electrical

or mechanical adjustment or repair.

11.DO NOT insert or allow fingers or foreign objects to enter any

ventilation or exhaust opening as it may cause an electric shock

or fire, or damage the Fan. DO NOT block or tamper with the Fan

in any manner while it is in operation.

12.This Fan is not intended for use in wet or damp locations.

Never locate a Fan where it may fall into a bathtub or other water

container.

13. DO NOT use Fan outdoors.
14.This Fan is not suitable for use in agricultural facilities including

areas where livestock, poultry or other animals are confined.
Please refer to National Electric Code (NEC) Article 547-7 (2008),
or applicable state or local codes or standards relating to electrical
requirements for Agricultural Buildings. THIS FAN DOES NOT MEET
THE REQUIREMENTS OF NEC ARTICLE 547-7 (2008).

15.This Fan is not suitable for use in hazardous locations. Please refer to

National Electric Code (NEC) Article 500 or applicable state or local
codes or standards relating to electrical requirements for Hazardous
locations. THIS FAN DOES NOT MEET THE REQUIREMENTS OF
NEC ARTICLE 500 (2008).

WARNING:

REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK – DO NOT USE THIS FAN WITH ANY SOLID STATE
SPEED CONTROL DEVICES.

SAVE THESE INSTRUCTIONS

Rev. E 2/08

8

2082048A

MODEL/MODELO 2EJR6G/9155G

NOTES/NOTAS

MODEL 2ERJ6G/9155G

SPEED HIGH MED

LOW

CFM

2470

1700

1360

M

3

/s

1.17

0.80

0.64

RPM

1480

1110

820

Amps 0.80

0.63

0.50

Watts 90

76

61

dB A

64

50

47
