GReddy TURBO KITS: Nissan 350Z 2003-04 / twin TD05-18G - Manual (Page 3)

1. Parts List
1. Turbocharger TD05-18G 8cm 2 2
2. Wastegate (GReddy / Tial) .45bar 2
3. Exhaust Manifold (Right Side) Ductile Iron Cast 1
4. Exhaust Manifold (Left Side) Ductile Iron Cast 1
5. Downpipe Adapter (Right Side) 1
6. Downpipe Adapter (Right Side) 1
7. Compression Pipe R C-1 (50 ∅ Aluminum Elbow No.6) 1
8. “ R C-2 (50 ∅ Aluminum) 1
9. “ R C-3 (50 ∅ Aluminum Elbow No.21) 1
10. “ L C-4 (50 ∅-70∅ Aluminum) 1
11. “ C-5 (50 ∅ Aluminum) 1
12. “ C-6 (80 ∅ Aluminum) 1
13. Airflow Meter Adapter 1
14. Suction Pipe R S-1 (60 ∅ Aluminum) 1
15. “ R S-2 (70 ∅ Aluminum) 1
16. “ L S-3 (60 ∅ Aluminum Elbow No.82) 1
17. “ L S-4 (70 ∅ Aluminum) 1
18. Airinx AY-SB (Blue) 2
19. Airinx Hose Adapter S70 2
20. Oil Pressure Hose SUS (R=600mm, L=800mm) _________________1 each
21. Oil Pressure Union Fitting 3-Way Fitting 2
22. “ 1/8PT – 1/8 PT Straight 2
23. “ 1/8PT – 1/8 PF Straight 1
24. “ 1/8PT – 1/8 PF Male to Male 90 ° 1
25. Oil Pressure Banjo Fitting Male and Female (small) 2
26. Copper Washer 10 ∅ (t=1.0) 4
27. Oil Return Pipe Right 16 ∅ 1
28. Oil Return Pipe Left 16 ∅ 1
29. Oil Pan with welded Oil Return Pipe 1
30. Vacuum Hose 5 ∅ x 100mm (Blue) 1
31. “ 6 ∅ x 2000mm (Blue) 1
32. Radiator Reserve Hose 7 ∅ x 10∅ x 790mm CR60° Tube 1
33. Rubber Hose 15 ∅ x 1140mm
(Oil Return 440mm, Blow By 300mm, Power Steering 200mm) 1
34. Silicone Hose 50 ∅ x 70mm Straight 6
35. “ 80 ∅ x 80mm Straight 2
36. “ 60 ∅ - 70∅ Reducer 2
37. “ 60 ∅ - 80∅ Reducer 2
