2. Removal of Stock & Turbo Kit Parts
When removing the stock parts, make sure you read over the factory
repair manual for proper procedures.
2­1 Disconnect the negative side of the battery.
2­2 Remove the undercover, and the front bumper.
2­3 Remove the bumper support beam.
2­4 Remove the two horns.
2­5 Remove the wind shield washer tank.
2­6 Remove the Turbo Kit Air intake, suction pipe, the suction adapter, and the restictor.
(refer to the Turbo Kit Installation Manual)
2­7 Remove the Turbo Kit Compression Pipe C­3and C­4.
(refer to the Turbo Kit Installation Manual)
3. Kit Installation
3­1 Body Modification
Cut the shaded area of the body at the left front
body as shown.
Intercooler Installation
(1) Install the Intercooler bracket to the body with
the horn as shown using the provided spacer
between the horn bracket and I/C bracket.
（Parts used #: 16, 17, 19,20)
(2) Mount the Intercooler shown using provided
hardware. Secure the left side of the intercooler
(looking from the front of the vehicle) to the
bracket installed in the previous step.
Spacer
