Label Qty. Description Part Number
A 1 Air Filter (Pro DRY S) 61-90127
B 1 Tube #1 Passenger side 05-T3017P1
C 1 Tube #2 Driver’s side 05-T3017P2
D 2 Tube #3 05-T3017P3
E 2 Coupling: Elbow 2-3/4” ID x 45 Deg 05-01190
F 2 Coupling: Straight 2-3/4” ID x 1-3/4”L 05-01107
G 8 Clamp, 044 03-50019
H 2 Hose, 5/8” (2 inches) 05-00069
I 4 Screw, M4 x .7 x 8 03-50034
J 4 Screw, Hex Hd: M6 x 1 x 12 03-50032
K 1 Nut, Hex: M6 x 1 03-50059
L 5 Washer, Flat: 1/4” 03-50043
Installation will require the following tools:
Phillips screw driver, 10mm socket, Extention, Ratchet, Pliers & 5/16 nut driver.
Note: Legal in California for use on race vehicles only. The use of this device on vehicles used on public
streets or highways is strictly prohibited in California and others states that have adopted California
emission regulations.
• Please read the entire instruction manual before proceeding.
• Ensure all components listed are present.
• If you are missing any of the components, call customer support at 949-588-8300.
• Ensure you have all necessary tools before proceeding.
• Do not attempt to work on your vehicle when the engine is hot.
• Disconnect the negative battery terminal before proceeding.
• Retain factory parts for future use.
