GReddy AIR INTAKE SYSTEMS: Scion tC 2011-14 User Manual

Page 5

Text mode
Original mode

Refer to Figure B for steps 6-7

Step 6: Remove the filter and the 3 bolts holding down the lower portion of the airbox using a

10mm nut driver. 6

Step 7: Remove the tube form the lower airbox using a 10mm nut driver. 7

REMOVAL

Page 5

GReddy.com

Figure B
