GReddy Multi D/A Gauge System - Manual (Page 5)

5.Remote setting – Operation
Water temperature
Oil pressure
Boost
Exhaust temperature
Backlight
Fuel pressure
Voltage
Down
Warning
Clear
Peak
Sound
Oil temperature
UP
Set
【Warning setting】 【Sound setting】
Press the warning setting button.
Select the item.
Set values by pressing
up / down buttons.
SET: Save your setting.
【Peak value display setting】 【Backlight setting】
Press the sound button to hear the current sound.
Each time pressing, the sound varies. “Set” to save your setting.
Setting 1 (PiPi--------)
Setting 2 (Pi-pipi, Pi-pipi)
Setting 3 (Pipi--Pipi)
SET to save your setting.
Each time pressing backlight button, the color varies as follows.
Peak button: Display peak value.
Select each item to display each peak value.
CLR: Clear everything.
SET: Back to the real time display.
Setting 4 (Silent)
Setting buttons
Exhaust temp up
○ To show 2 items – The first press, the item comes on the top, and the second, the previous item comes down & new item comes up.
The third press, the bottom item disappears.
○ To show 1 item – Press the button twice to show the desired item sole.
○ Press SET to save your setting.
【Display setting】
(Example)
【Special operations】
Press & hold two buttons at the same time to reset.
Restart: Shut down and start again.
Reset: Back to the factory default
※Operating sound : PiPiPiPiPi Pi-PiPiPi
※Operating sound : Pi--PiPiPi Pi--PiPiPi Pi--PiPiPi
White
Green Red
Blue Yellow
Purple
Light blue
-5-
※Idle for 5 seconds, get back to the real time display.
Fuel pressure up
Exhaust temp down
Water temp up
Fuel pressure down
Water temp
only
