350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11027199
55-57 Chevy Rear AirBar
(One Piece Frame)
Components:
1
90000160 Driver side lower axle bracket
1 90000558 Passenger side lower axle bracket
1 90000556
Front cross member (33.688”)
1 90000554 Upper shock mount
1 90000555 Upper shock mount
4 90000552 Heim end spacer for diagonal bar
1 90000550 Lower shockwave mount
1 90000551 Lower shockwave mount
8 90001942 Pressed into bars
4 90000956 Parallel Bars C- C 18.50”
1 90000941 Diagonal bar C-
C 30.25”
2 90001617 5/8” Shock studs
1 90000266 Brake line tab
4 90001584 Rod end
2 90001589 Heim end for Diagonal link
6 99752004
¾”-16 Hex jam nut for rod ends
4 90002067 Aluminum spacer – lower shock bearing
Hardware Kit Part # 99010019:
4
1/2” x 3/4” Gr. 8 bolt
Lower Shockwave Mount
10 5/8” SAE Gr.8 Nyloc Jam nut Bar ends
8
5/8” x 2 3/4" SAE Grade 8 bolt
Bar ends
2 5/8” x 3” SAE gr.8 bolt Bar ends with diagonal link mounts
2 1/2" x 2 1/4" SAE bolt Upper Shockwave mount
2 1/2" SAE Nyloc jam nut Upper Shockwave mount
20
3/8” x 1” type F thread forming bolt
Crossmember and upper Shockwave mount
20 3/8” Lock washer Crossmember and upper Shockwave mount
2 #10 x 3/4" Tek screws Brake line bracket
