Hardware Kit – Part # 99010008
4 3/8 x 3/4 uss bolts upper air spring mounting
6 3/8 lock washer air spring mounting
6 3/8 x 1 uss bolt air spring mounting & carrier bearing plate
4 3/8 nyloc nuts carrier bearing plate
10 3/8 sae flat washers carrier bearing plate & air spring mounting
6 7/16 x 1 1/4 uss bolt upper frame bar mount
12 7/16 uss flat washer upper frame bar mount
6 7/16 uss nyloc nuts upper frame bar mount
46 1/2 x 1 1/2 uss bolts C-notch to frame & upper bridge
92 1/2 sae flat washers C-notch to frame & upper bridge
48 1/2 uss nyloc nuts C-notch to frame, upper bridge & shocks
2 1/2 x 2 1/2 uss bolts lower shock mounting
1 5/8 lock washer (gr. 8) Heim end to axle cover brk.
8 5/8 x 2 3/4 sae bolts (gr. 8) rod ends to brackets & panhard bar axle bracket
7 5/8 sae nyloc jam nuts (gr. 8) rod ends to brackets
8 5/8 x 6 sae bolts (gr. 8) bridge to axle
8 5/8 sae nyloc nuts (gr. 8) bridge to axle
16 5/8 sae flat washers (gr. 8) bridge to axle
5 3/4 sae jam nuts lock nuts for rod ends
5 m8x40mm bolts panhard bar mount to axle cover
5 m8 flat washers panhard bar mount to axle cover
5 m8 lock washers panhard bar mount to axle cover
NOTE: oem spring hanger bolt is used for lower front bar to spring hanger!
