Removal of oem column – ididit Right Hand Drive & Collapsible Steering Column: RHD 1968-69 Mustang User Manual

Page 3

Now go under the dash and disconnect the
wire plug from the column to the under dash
harness. (Figure 3)

Remove the 4 bolts that hold the lower floor
mount to the firewall toe board. Remove
the bolts or bolt that attach the floor mount
to the column. Since we are working on in-
structions for both a ‘68 (Figure 4) and or ‘69
Mustang, they have a lot in common. We will
be talking about both and each at the same
time.

Remove the two piece floor mount on the ‘68
by separating the two halves. On the ‘69 it is
a clamp with one bolt.

Before we get to far we need to remove the bolt that holds the rag joint on
the steering box. You may want to spray some penetrating oil on the bolt
before you take it out.

(Figure 3)

REMOVAL of OEM Column:

Disconnect positive battery cable.

(Figure 4)

To remove the horn button on your stock steering wheel, push it in an then

rotate counter clockwise. (Figure 1)

Remove the nut and use a wheel pull-
er to pull the original steering wheel
off the original column. (Figure 2)

(Figure 1)

(Figure 2)
