5.
Turn Signal Switch
#1 Orange w/Blue or Orange Left rear turn and brake
#2 Green w/Orange Right rear turn and brake
#3 Not Used
#4 Not Used
#5 White w/Blue Left front turn signal
#6 Yellow Horn (Power)
#7 Green w/White Right front turn signal
#8 Green Brake feed from brake switch
#9 Blue w/Yellow or Yellow Horn (‘65) Yellow w/Green)
(‘66) Blue w/Yellow
#10 Blue Turn signal feed
*Included with the connector are new terminals for the car side if your originals are not usable or if you
have an aftermarket harness and do not have matching terminals.
Wiring Installation:
(Cont.)
Column Installation:
Install the coupler on the column by sliding it on the column shaft and
securing it with a set screw and lock nut.
Tip..
Please follow the manufactures instructions on the Coupler installation. These
instructions vary by manufacturer. But when all is said and done, ididit recommends that
you use Locktite on the threads.
Next, slide the floor mount plate, clamp, and gasket up the tube of the
new column. The nut on the clamp should be on the bottom of the tube
and facing the driver. You can temporarily hold the mount in place with
a piece of masking tape while you install the column in the car.
1
2
3
4
5
6
7
8
9
10
