ididit Retrofit Steering Column: 1974-77 Ford Bronco - Manual (Page 7)

5
Knobs & Levers:
After removing all items from the package,
assemble the knobs onto the levers. The tilt
lever (shorter of the two levers) goes on the
left side of the column in the hole closest to
the dash. The column has a threaded hole
that this lever threads into. (Figure 15A)
The turn signal lever (longer of the two
levers) goes on the left side of the column
in the hole closest to the driver. The column
has a threaded hole that this lever threads
into. (Figure 15B)
Shift Indicators: Due to the many
transmissions used in vehicle applications,
ididit does not include one with this kit.
C-4, C6 or other gearshift indicators are
a separate piece, but an available option
through ididit. The Shift Indicators are
available in Chrome, Black Powder Coated, Brushed or Polished
Aluminum.
Wheel Installation: This column was designed to use a stock Ford
steering wheel. Just slide it on the top shaft and push it down onto
the splines. Use the nut that was supplied with the new column,
place it on top of the columns top shaft. To secure the wheel
tighten the nut to 45 ft lbs of torque. Install the OE horn assembly
to the wheel and use the factory screws to hold it into place.
Reconnect the battery terminals to the battery.
Floor Shift: If installing a floor shift column your installation is now
complete.
Column Shift: If you are installing a column shift column you need
to hook the transmission gear shift rod going from the column to the
transmission back up.
(Figure 15 A & B)
A.
B.
