ididit Retrofit Steering Column: 1974-77 Ford Bronco - Manual (Page 4)

2
Disconnect the stock wiring plug halves. (Figure 5)
Move to the inside of the vehicle and
remove the 4 bolts that hold the floor
plate to the firewall. (Figure 6)
Remove the 4 screws that hold the
steering column dash cover (Stock is
plastic, the one pictured is aluminum).
(Figure 7)
In the engine compartment remove the
3 bolts that hold the triangular bracket
(bracket is against the firewall under
the Steering Column). (Figure 8)
Back in the cabin there are two bolts
that hold the column to the dash frame
work. You can get to them from the 2
holes on the bottom of the dash shown
in picture. (Figure 9) Once removed
take the stock column out carefully
and put it on a bench or floor out of the
way for a while.
(Figure 7)
(Figure 8)
(Figure 9)
(Figure 5)
(Figure 6)
