8.1.1 Display Description
The alpha-numeric display indicates the following:
• Parameter number
• Parameter value
• Fault code
8.1.2 LED Descriptions
Refer to figure 8.1 for the location of the LEDs described in table
8.1.
Table 8.1 – LED Descriptions
No. LED LED State Description
➊ RUN Steady Red Indicates the drive is running.
➋ FWD
REV Flashing
Red Drive has been commanded to
change direction. Indicates actual
motor direction while decelerating
to zero.
Steady Red Indicates the commanded motor
direction.
➌ VOLTS
AMPS
HERTZ Steady Red Indicates the units of the
parameter value being displayed.
➍ PROGRAM Steady Red Indicates the drive is in program
mode and the parameter value
can be changed.
➎ FAULT Flashing
Red Indicates drive is faulted.
➏ Pot Status Steady
Green Indicates potentiometer on
integral keypad is active.
➐ Start Key Status Steady
Green Indicates Start key on integral
keypad is active. The Reverse key
is also active unless disabled by
A095 (Reverse Disable).
