Accessories
E-1
A
PPENDIX
E
Accessories
E.1
Dynamic Brake Modules
Table E.1 – Dynamic Brake Modules
Drive Ratings
Model Number
1
1
The resistors listed in this table are rated for 5% duty cycle.
Input Voltage
kW
HP
Minimum
Resistance
(ohms)
120V 50/60 Hz
1-Phase
0.2
0.25
-
AK-R2-091P500
0.75
1.0
-
AK-R2-091P500
0.75
1.0
60
AK-R2-091P500
1.1
1.5
60
AK-R2-091P500
240V 50/60 Hz
1-Phase
0.2
0.25
-
AK-R2-091P500
0.4
0.5
-
AK-R2-091P500
0.75
1.0
60
AK-R2-091P500
1.5
2.0
60
AK-R2-091P500
240V 50/60 Hz
3-Phase
0.2
0.25
-
AK-R2-091P500
0.4
0.5
-
AK-R2-091P500
0.75
1.0
60
AK-R2-091P500
1.5
2.0
60
AK-R2-091P500
2.2
3.0
48
AK-R2-047P500
3.7
5.0
32
AK-R2-047P500
480V 50/60 Hz
3-Phase
0.4
0.5
-
AK-R2-360P500
0.75
1.0
121
AK-R2-360P500
1.5
2.0
121
AK-R2-360P500
2.2
3.0
97
AK-R2-120P1K2
3.7
5.0
97
AK-R2-120P1K2
