6.0 PRODUCT SPECIFICATIONS
VisionAire
™
2 and VisionAire
™
3
Flow Specification s
(1)
½ lpm – 3 lpm
⅛ lpm – 2 lpm
±10% of indicated setting, or 200 mL, whichever is greater (1)
Oxygen Concentration (1) 90% (+ 5.5% / - 3%)
Electrical Requirements
115 VAC / 60 Hz, 3.0 A
230 VAC / 50 Hz, 1.5 A
230 VAC/ 60 Hz, 1.5 A
Power Consumption
VisionAire 2 = 200 Watts (+/- 10%)
VisionAire 3 = 175 Watts (+/- 10%)
Sound 40 dba
Dimensions
14.1 in. W x 11.5 in. D x 20.8 in. H
(35.8 cm W x 29.2 cm D x 52.8 cm H)
Weight 30 lbs (13.6 kg)
Electrical Shock
Protection
Class II, Type B
Environmental Limit
Conditions
(2)
Operating conditions: 5 o C to 40 o C (41 o F to 105 o F ) at
altitudes up to 10,000 ft.(523mmHg) above sea level.
Storage: -20
o
C - 60
o
C (-4
°F - 140°F)
Relative Humidity: up to 95% RH non - condensing
(1) Performance based at 21
°C (70°F) at nominal operating pressure range: 0-7 kPa
(0-1 psig backpressure). Maximum outlet pressure : 55 kPa. ( 7.98 psig)
(2) Operating outside of these operational specifications can limit the concentrators ability
to meet Oxygen Concentration specification at higher liter flow rates.
