Bridging: NetVanta 3000 Series Routers
Page 5
5. Frame-Relay Multipoint – Multipoint bridging applications are useful for two remote offices that
have small traffic requirements and need to access local office resources (desiring minimal
changes to the local and main office servers). If all resources are using NetBEUI protocol,
bridging is the only option. There are minimal differences when configuring point-to-point and
multipoint applications (including frame relay configuration and assigning all sub-interfaces
(PVCs) to the bridge group). The complete configuration for multipoint bridging is shown
below and is annotated to highlight the differences from the point-to-point application.
Frame Relay Multipoint Bridging Configuration
no ip routing
!
interface eth 0/1
full-duplex
speed auto
ip address
192.168.4.1 255.255.255.0
bridge-group 1
bridge-group 1 spanning-disabled
no shutdown
!
interface ser 1/1
no shutdown
!
interface bri 1/2
shutdown
!
!
Note that a frame relay virtual interface is created
interface fr 1 point-to-point
no shutdown
cross-connect 1 ser 1/1 frame-relay 1
!
!
Here are the two sub-interfaces to the remote locations
interface fr 1.16 point-to-point
frame-relay interface-dlci 16
no ip address
bridge-group 1
bridge-group 1 spanning-disabled
!
interface fr 1.17 point-to-point
frame-relay interface-dlci 17
no ip address
bridge-group 1
bridge-group 1 spanning-disabled
bridge 1 protocol ieee
