Roll Media
Loading Roll Media Guidelines
Hints and tips on loading the media. Including how to
install three inch adapters.
Installing Roll Media into the Printer
This section shows you how to:
– Install media onto a spindle.
– Install the roll of media in the correct orientation
into the printer.
Trimming the Media
Before loading media into the printer, make sure the
edge is straight. The animation shows you how to trim
manually the media.
Loading Roll Media
This section shows you how to load media into the
printer and the Take Up Reel.
Printing of Both Sides of the Media
This section shows you how to print on both sides of
the media.
Unload Media from Take Up Reel
This section shows you how to unload the media from
the Take Up Reel.
Unloading Roll Media
This section shows you how to unload the media from
the printers’ internal media path.
Change the Core Tube
This section shows you how to unload the media from
the core tube. The core tube is the tube which the Take
Up Reel winds media onto as it prints.
Media Length Tracking
This section describes how to turn on and off the media
length tracking function.
