Loading Roll Media
This procedure shows you how to install media onto
the printer. It includes references to the Take Up
Reel.
Front panel messages which are only applicable
if you have a Take Up Reel installed are
highlighted in green.
If your printer is the HP Designjet 42inch/ 1.07m
the Take Up Reel is an optional accessory. See
Ordering Accessories .
To start this procedure you need to have a roll of
media installed on to the printer spindle. See
Installing Roll Media into the Printer .
The animation shows the Media Length tracking
function turned On. To switch Off the tracking,
see
Media Length Tracking .
Read Loading Roll Media Guidelines and then click on this icon to run the animation sequence.
A printable version of the sequence is also available so that you can take the key illustrations
to the printer, if it is remote from your computer.
