Setup 13
• Install drives in the D2220sb before installing the D2220sb in the enclosure.
• Be sure that the partner server blade is powered down before installing the D2220sb.
Onboard Administrator is used to configure the enclosure and the D2220sb. To function with the D2220sb,
Onboard Administrator version 3.60 or later is required.
Additional guidelines for installation with a half-height partner
server blade
When installing the D2220sb with a half-height server blade, observe the following additional guidelines:
• Install the D2220sb in any device bay.
• If the D2220sb is installed in an odd-numbered bay, install the partner server blade in the adjacent
even-numbered bay to the right.
• If the D2220sb is installed in an even-numbered bay, install the partner server blade in the adjacent
odd-numbered bay to the left.
Additional guidelines for installation with a full-height partner
server blade
When installing the D2220sb with a full-height server blade, observe the following additional guidelines:
• Remove the device bay shelf.
CAUTION: Failure to install the divider in a quadrant when installing half-height blades can
result in damage to the connectors on the server blades.
• Install the half-height blade shelf on the D2220sb.
• Install the D2220sb in any device bay on the lower row of the enclosure (9 through 16).
If installing two D2220sb storage blades with one full-height partner server blade, install the second
D2220sb in the bay directly above the first one. The top D2220sb does not require a half-height blade
shelf.
If installing two D2220sb storage blades with one partner server blade in an HP BladeSystem c3000
Enclosure, use the mini divider instead of the half-height blade shelf. For more information, see the HP
BladeSystem c3000 Enclosure Quick Setup Instructions.
• If the D2220sb is installed in an odd-numbered bay, install the partner server blade in the adjacent
even-numbered bay to the right.
• If the D2220sb is installed in an even-numbered bay, install the partner server blade in the adjacent
odd-numbered bay to the left.
• When installing the D2220sb with a full-height server blade, a half-height server blade can be installed
in the empty bay above the D2220sb. This server blade cannot be partnered with the D2220sb.
Installing a storage blade
CAUTION: To prevent improper cooling and thermal damage, do not operate the D2220sb or
the enclosure unless the first drive bay is populated with a drive, and drive bays 2 and 3 and all
