Figure 9 Set LUSE Confirmation Dialog Box
The LUSE components list in this dialog box show information about the LDEVs that constitute the
LUSE volume.
Table 8 LUSE Components List
Description Item
LDEV status icon and the LDKC, CU, and LDEV numbers.
•
An LDEV number ending with # (for example,
00:00:01#) indicates that the LDEV is an external
volume. For details about external volumes, see the HP
StorageWorks XP24000/XP20000 External Storage
Software User Guide.
•
An LDEV number ending with V (for example, 00:00:01
V) indicates that the LDEV is a virtual volume (V-VOL)
for XP Snapshot. For details about V-VOLs, see the HP
StorageWorks XP24000/XP20000 Snapshot User
Guide.
LDKC:CU:LDEV
Emulation type of the LDEV. Emulation
Capacity of the LDEV. Capacity
Creates the LUSE volume. Click this button to set the LUSE
volume configuration having the LDEVs in the LUSE
component list. The LDEVs registered as components of the
LUSE volume are displayed in blue bold italics in the LDEV
information list OK
Cancels the operation to create a LUSE volume using the
LDEVs in the list. Cancel
Creating a LUSE Volume From the LDEV Operation Detail (Select an LDEV Box)
To create a LUSE volume from the LDEV Operation detail (Select an LDEV box):
Creating a LUSE Volume 23
