Hardware options installation 39
3. Install the drive.
4. Determine the status of the drive from the drive LED definitions (" Hot-plug drive LED definitions " on page
13 ).
Installing the single or double SFF hot-plug drive cage options
The following configurations are supported for the front components in the server.
Left bay Right bay
Low profile PCIe card FlexibleLOM
Low profile PCIe card SFF hot-plug drive cage
SFF hot-plug drive cage FlexibleLOM
SFF hot-plug drive cage SFF hot-plug drive cage
NOTE: An SFF hot-plug drive cage cannot be connected to a controller card.
1. Power down the server (on page 15 ).
2. Remove the server from the chassis (on page 15 ).
3. Remove the FlexibleLOM riser cage.
