Back of printer
1 Rear access door: Open this door to clear a paper jam.
2 USB port: Use this port to connect a computer to the printer.
3 Power cord connection: Use this port to connect the power cord included with the printer.
Control panel
1 Select Photos arrows: Scroll through the photos and control video playback on a memory
card.
2 OK: Select a menu or dialog choice and play/pause a video clip during playback.
3 Print: Print selected photos from the inserted memory card.
4 Cancel: Deselect photos, to exit a menu, or to stop an action you have requested.
5 Menu: View the printer menu.
6 Layout: Choose a photo layout.
7 HP Instant Share: Send a photo via e-mail (if connected). For more information, see
Getting connected .
8 Zoom: Enter Zoom mode and zoom in on the currently displayed photo, and to exit 9-up
view mode.
9 Rotate: Rotate the currently displayed photo.
HP Photosmart 8000 series User's Guide 5
