4.3 First Setup

checks

Disable the MUTE function on the outputs you intend using and listen the sound, carry out instrumental

(if you have the necessary equipment) and any corrections required.

4.4 System configuration

The bold letters indicate the inputs:
A = Input A
B = Input B
S = SUM (sum of inputs A and B)

2 x 2 W + 2 M A X

A 1 3

B 2 4

S 5 6

I N A

G A I N

& B

. 0 d B

I N A

G A I N

. 0 d B

I N A

G A I N

. 5 d B

I N A

G A I N

& B

. 0 d B

Firstly, set the following parameters

in order:

shown

Output Pol. Polarity of the outputs
Xover Crossover frequencies (separation of the speaker channels)
Output Delay Alignment of the speaker enclosure components
Output Gain Levels of the outputs

Then, if necessary, adjust the values of the following functions:
Output EQ Output equalizers
Output Limiter Output limiters

Use the

to change the gain value and watch the level of the signal on the LED ladders until the ideal values

DIAL

are reached.

Then use the

and

keys to access to the

page (if there is one, this will depend on the con-

PREV

NEXT

INB Gain

figuration and the other utilities loaded in the memory).
Repeat the settings as explained above.

At this point, the first custom setup can be prepared.
The following is only the description of setup procedure.
The detailed specifications of each parameter are shown in the respective paragraphs of the manual.

Note: The regulation of the MAXIDRIVE3.4's parameters is closely related to the characteristics of the com-

ponents of the sound system. So if you're not the expert, please refer to the documentation and technical
specifications of your power amplifiers, loudspeaker enclosures, monitors, etc.. This will enable you to
work faster and safely.

Note: In this first phase of setting up your sound system, the adjustment of these functions (which if not Indis

-pensable during installation) can wait. But do remember that adjusting the equalizers can also affect the
signal level. So if considerable equalization changes are made, remember to check and adjust the output
levels too, if necessary.
