Installing CD-Writer Plus and Software English-7
E
n
g
lis
h
14. Set the jumper on the CD-Writer Plus as advised in the Install
Recommendation Printout for your computer.
15. Insert the drive into the selected drive bay. Be careful not to dislodge any
cables inside your computer as you do this.
If you are replacing an existing CD-ROM, skip to step 19 on page 8.
16. If you are installing in an empty drive bay, look at the Install
Recommendation Printout again and find whether the data cable should
be connected to the computer’s primary or secondary IDE controller.
or Master
Check the back of the new drive and
make sure the jumper is on the right-
hand location (Master).
Slave
Check the back of the new drive and
make sure the jumper is on the center
location (Slave).
This is a jumper. You can pull it
off and place it on another pair
of pins to change the setting.
Don’t use
Cable Select
