HP ProLiant DL360e Gen8 Server User Manual
Page 74
Cabling 74
•
Eight-bay SFF drive cage connected to the P430 controller in the full-height expansion slot
Item
Description
1
Power cable
2
Capacitor pack cable
3
Mini-SAS Y-cable
•
Eight-bay SFF drive cage connected to the P430 controller in the low-profile expansion slot
Item
Description
1
Power cable
2
Capacitor pack cable
3
Mini-SAS Y-cable
