Component identification 10
Item Description
1 PCI riser connectors*
2 Cache module connector
3 TPM connector
4 Mini-SAS connector
5 System battery
6
SATA drive connector
7 SATA optical/storage drive connector
8 Front panel connectors
9
Processor socket 1
10 GPU power connector
11 Fan connector 8
12 Fan connector 7
13 Fan connector 6
14 Fan connector 5
15 Fan connector 4
16 Internal USB connector
17
Fan connector 3
18 Fan connector 2
19 Fan connector 1
20 Processor 2 DIMM slots
21
Reserved
22 Drive backplane power connector
23 Processor socket 2
24 Reserved
25
Power supply connector 1
26 Drive sideband signal connector
27 Power supply connector 2
28 Processor 1 DIMM slots
29
SD card slot
30 NMI header
31 System maintenance switch
* For more information on the riser board slots supported by the onboard PCI riser connectors, see "PCIe riser
board slot definitions (on page 9 )."
