Overview and Features

N1526A and N1527A ACL Tape Drive Installation and User’s Guide— 542756-003

1 -2

NonStop NS-Series Servers

NonStop NS-Series Servers

An M8201R Fibre Channel to SCSI router must be used to connect the tape drives to
the Fibre Channel ServerNet Adapter (FCSA) on the HP NonStop NS-series server.

For more information, see the M8201R Fibre Channel to SCSI Router Installation and
User’s Guide and the Fibre Channel ServerNet Adapter Installation and Support
Guide.

Figure 1-1. Hardware Configuration

NonStop S-Series

Tape Drive

SCSI Cable

ServerNet/DA,
IOMF2 CRU, or
PMF CRU

Server
