ARTURIA – MOOG MODULAR V 2.6 – USER’S MANUAL
93
7.2.6
Sequence generator
Sequencer
Also called sequencer, this module is similar to the original Moog 960 sequencer while
simplifying the programming with internal connections.
This module has 3 parts: low frequency oscillator, the 8-step sequence manager and the
output controller.
Sequencer clock
Frequency
Sets the sequencer clock speed
On
Starts the sequencer
Off
Stops the sequencer
On Input Trigger
Connection of a trigger signal to start the sequencer
Off Input Trigger
Connection of a trigger signal to stop the sequencer
Length
Length of the trigger signal generated by the sequencer
MIDI Synchronization
Synchronization of delay with host application tempo
Next Trigger
Connection of a trigger signal for the passage to the next step
Fw - Fw/Bw
Select the sequencer mode (forward, or forward/backward)
Frequency
Off
Fw / Rw
Length
On
On / Off Input Triggers
MIDI Synchronization
Next Trigger
