112 ARTURIA – MOOG MODULAR V 2.6 – USER’S MANUAL
Create a link between these 2 VCA by clicking on the “link” button situated between the
first and second VCA. This will allow you to mix these 2 sources before directing them
towards the audio input of filter1.
Click on the link button to create a link between the 2 VCA
To connect the audio output coming from the 2 mixed VCA to the filter1 input, drag a cable
from the first VCA “out” to the filter1 “in”.
Link towards filter1
As was the case with the previous patch, direct the filter output towards the audio input of
the output VCA 1.
Now increase the volume of these 2 VCA (volume knobs) so as to hear the sound coming
from the 2 oscillators.
Setting of the volume of the 2 mixer VCA
