90 ARTURIA – MOOG MODULAR V 2.6 – USER’S MANUAL
7.2.3 Chorus
Chorus
Types Sets the 3 chorus Types
Rate Sets the chorus rate
Depth Sets the depth of the chorus action
Time Sets the delay applied to the input signal
Stereo Rate Sets the speed of the stereophonic evolution
Stereo Width Sets the width of the stereophonic space
Dry Sets the gain applied to the input signal
Wet Sets the gain applied to the treated signal
VCA1-VCA2 Connection of the chorus to the output of VCA1 or VCA2
A Chorus module allows the treatment of the signal coming from the 2 output amplifiers,
eventually treated by the equalizer, in function with the state of the interrupters “VCA1” and
“VCA2”.
The chorus module allows a frequential blurring where the speed is set by the “speed” knob,
the amplitude by the “depth” and the width with the “Delay”. This frequency blurring is
different for the left and right tracks. This allows us to get a stereophonic signal from a
monophonic signal. The difference between the 2 tracks can be set with the “stereo width” and
the speed of the left right rotation with the “stereo rate” knob.
A selector presents the choice of chorus type: simple, medium, complex.
The input signal level and treated signal can be respectively set with the “gain direct” and
“gain effect” knobs.
Rate
Depth
Time
Stereo Rate Stereo Width
Wet Dry
VCA1-VCA2
Types
