ARTURIA – MOOG MODULAR V 2.6 – USER’S MANUAL 83
Serial mode
7.1.9 Noise generator
Noise generator
Low Pass Frequency Sets the low-pass filter cut-off frequency
Low Pass Input Low Pass filter input connection jack
Low Pass Output Low Pass filter output connection jack
Low Pass Frequency Sets the Low Pass filter cut-off frequency
High-pass Output High-pass filter output connection jack
High-pass Input High-pass filter input connection jack
White Noise White noise output connection jack
Pink Noise Pink noise output connection jack
The noise generator allows the simultaneous management of a white and pink noise. It also
possesses a low-pass and a high-pass of the first order (6 dB/octave) in which the cut-off
frequency can be statically set with the “frequency” knobs.
Low Pass Frequency
High Pass Frequency
Low Pass Output
High Pass Output
White Noise
Pink Noise
Low Pass Input
High Pass Input
