CWDM Slot A 4-port Add/Drop Multiplexer and CWDM Slot
B 4-port Add/Drop Multiplexer specifications
Table 4 CWDM Slot A 4-port Add/Drop Multiplexer and CWDM Slot B 4-port Add/Drop
Multiplexer specifications
Attribute Description Unit measurement/Range
Module size
21.21 cm x 4.45 cm x 26.42 cm
(8.35 in x 1.75 in x 10.4 in)
Physical dimensions
Rack mount 1RU
Network side 2 dual LC
Equipment side 4 dual LC Connectors
Monitor side 2 dual LC
Operating 0°C to 70°C (32°F to 158°F)
Environment
Storage –40°C to 85°C (–40°F to 185°F)
Wavelength usage Unidirectional
Rx Network to Tx equipment
<1.5dB
Rx Equipment to Tx network <1.5dB Typical insertion loss
Pass through (network-to-network) <1.7dB
Rx Network to Tx equipment 1.8dB
Rx Equipment to Tx network 1.8dB
Pass through (network-o-network) 2.1dB
Maximum Insertion Loss
Monitor port 23dB
Add ≥30dB
Drop ≥30dB
Pass through ≥15dB
Isolation
Inter-CWDM port ≥50dB
Configuration Supported network configuration Ring or point-to-point
1470nm
1490nm
1510nm
HP StorageWorks CWDM slot A
4–port add/drop multiplexer
Wavelengths
1530nm
1550nm
1570nm
1590nm
HP StorageWorks CWDM slot B
4–port add/drop multiplexer
Wavelengths
1610nm
Compliance CE,FCC Class A,Class 1 Laser per US FDA CDRH-21-CFR 1040
26 HP CWDM MUX modules specifications
