A HP CWDM MUX modules
specifications
CWDM 8-port Multiplexer/Demultiplexer module specification
Table 3 HP StorageWorks CWDM 8-port Multiplexer/Demultiplexer specification
Attribute Description Unit measurement/Range
Physical dimensions Module size
21.21 cm x 4.45 cm x 26.42 cm
(8.35 in x 1.75 in x 10.4 in)
Rack mount 1RU
Network side 1 dual LC
Equipment side 8 dual LC Connection
Monitor side 1 dual LC
Operating 0°C to 70°C (32 F to 158° F)
Environment
Storage –40°C to 85°C (–40°F to 185°F)
Wavelength usage Unidirectional
Rx Network to TX Equipment
<1.7dB
Rx Equipment to Tx Network <1.7dB Typical insertion loss
Monitor port <23 dB
MUX ≥30dB
DeMUX ≥30dB Isolation
Inter-CWDM ports ≥50dB
Configuration Supported network configuration Ring or point-to-point
1470nm
1490nm
1510nm
1530nm
1550nm
1570nm
1590nm
HP StorageWorks CWDM 8–port
Multiplexer/Demultiplexer
Wavelengths
1610nm
Compliance CE, FCC Class A, Class 1 laser per US FDA CDRH-21–FR 1040
