3
Assembling and preparing
Item
Connection panel
Description
(1)
Touch USB
Connects a touch USB cable from the computer to the display.
HDMI
Connects voice or audio input cable.
DP IN
Connects DisplayPort in cable to the display.
DP OUT
Connects DisplayPort out cable to the display.
LAN/VOE
Connects a local area network cable.
SPEAKER OUT
Connects optional external speakers to the display.
AUDIO IN
Connects an audio cable to the display.
RGB/AV COMPONENT OUT
Connects an RGB/AV component out cable to the display.
RGB/AV COMPONENT IN
Connects an RGB/AV component in cable to the display.
RS-232C OUT
Connects an RS-232C out cable to the display.
RS-232C IN
Connects an RS-232C in cable to the display.
USB
Connects a USB cable to the display.
IR IN
Connects an IR cable to the display.
5
