7. Use the front panel feed menu to feed enough additional media through the media feederto provide
two full turns on the take-up reel (Refer to
Perform a manual media feed ).
8. At the rear of the printers, set the white media winding direction switch (1) to the OFF position.
9. Turn the take-up reel by hand (in the required direction—for inner or outer take-up) until two full turns
have been wound onto the reel.
10. Feed enough additional media through the media feeder to create a slack area (approximately 30 cm)
in the media sufficient to install the tension bar.
11. Mount the flanges on the tension bar, refer to Tension bars .
12. Adjust the positions of the flanges (1) on the tension bar, on the take-up side, to the width of the media.
118 Chapter 3 How do I use dual media rolls? ENWW
