46 Volume Management for the XP10000/XP12000
NOTE: A mainframe volume’s management area capacity is expressed in cylinders.
NOTE: An open system volume’s management area capacity is expressed in kilobytes.
NOTE:
• The xx is a variable indicating one or more numbers or letters.
• Boundary values are expressed in kilobytes.
• Boundary values of external volumes are always one kilobyte, regardless of RAID levels.
Table 17 Management area capacity of mainframe volumes
Emulation type Management area capacity
3380-3, 3380-3A, 3380-3B, 3380-3C, 3380-K, 3380-KA, 3380-KB,
3380-KC, NF80-K, NF80-KA, NF80-KB, NF80-KC
7
3390-3, 3390-3R, 3390-3A, 3390-3B, 3390-3C 6
3390-9, 3390-9A, 3390-9B, 3390-9C 25
3390-M, 3390-MA, 3390-MB, 3390-MC 53
3390-L, 3390-LA, 3390-LB, 3390-LC 23
3380-F, NF80-F 22
Table 18 Management area capacity of open-system volumes
Emulation type Management area capacity
OPEN-V 0
OPEN-3 5,760
OPEN-8 19,440
OPEN-9 19,440
OPEN-E 13,680
Table 19 Boundary value for RAID levels
Emulation type Boundary value
for RAID1 (2D+2D)
Boundary value
for RAID5 (3D+1P)
Boundary value
for RAID5 (7D+1P)
Boundary value
for RAID6 (6D+2P)
3380-xx 768 1,152 2,688 2,304
3390-xx 1,024 1,536 3,584 3,072
OPEN-xx (except for
OPEN-V)
768 1,152 2,688 2,304
OPEN-V 1,024 1,536 3,584 3,072
Table 20 Capacity of slots
Emulation type Capacity of slot
3380-xx, NF80-xx 48
3390-xx 64
