ASUS M2R-FVM
1-13
5. When the fan and heatsink assembly is in place, connect the CPU fan
cable to the connector on the motherboard labeled CPU_FAN.
Do not forget to connect the CPU fan connector! Hardware monitoring
errors can occur if you fail to plug this connector.
R
M2R-FVM
M2R-FVM CPU Fan Connector
CPU_FAN
GND
CPU F
AN PWR
CPU F
AN IN
CPU F
AN PWM
