xi
M2R-FVM specifications summary
Internal connectors 4 x USB 2.0 connectors
1 x Floppy disk drive connector
1 x IDE connector for two devices
4 x Serial ATA connectors
1 x CPU / 1 x Chassis fan connectors
1 x IEEE 1394a connector
1 x S/PDIF Out connector
Front panel audio connector
AUX audio in connector
24-pin ATX power connector
4-pin ATX 12 V power connector
System panel connector
BIOS features 4 Mb AWARD BIOS, PnP, DMI, WfM2.0, ACPI 2.0c,
SM BIOS 2.3, CrashFree BIOS2, EZ Flash,
Special H/W write protection
Manageability WOR by Ring, WOL by PME, WOR by PME,
Wake on USB from S1, S3, S4
Power requirements ATX power supply (with 24-pin and 4-pin 12 V plugs)
ATX 12 V 2.0 compliant
Drivers Chipset update driver
On-board graphic driver
Bus master IDE driver
RAID driver
Audio driver
LAN driver
AMD AWAY mode driver
Utilities & Applications BIOS flash utility under DOS
ASUS Update - BIOS
AMD Cool’n Quiet Utility
*Specifications are subject to change without notice.
