9
2 Connect the power cord.
• Plug the smaller end of the power cord into the jack labeled 9VAC on the back
of the system.
• Plug the other end of the power cord into an electrical outlet not controlled by
a wall switch.
NOTE: For table installation only, flip out the bracket under the unit, and fit the power
cord through the strain-relief tab.
Use only the power cord supplied with your answering system. If you need a
replacement cord, call 1 800 222–3111.
Input: 120V, 60 Hz
Output: 9V AC, 400 mA
Wall Installation
1 Choose a location near a modular telephone jack and a standard electrical outlet
not controlled by a wall switch.
INSTALLATION
