Page 7
the SPOCK website
) for the most recent information about
the operating system versions that are supported.
Power specifications
For a detailed product specification, please refer to the QuickSpecs available from our website
).
Table 1 Power specifications for LTO Ultrium half-height tape drives
All other LTO Ultrium half-height
tape drives
LTO–5 Ultrium 3000
LTO–6 Ultrium 6250
13 Watts idle
7.5 Watts idle
4.5 Watts idle (hibernate)
Power
consumption
20 Watts typical
24 Watts typical
29 Watts typical (writing)
33 Watts maximum
40 Watts maximum
42 Watts maximum
+5V @ 2.5A typical
+5V @ 4.1A typical
+5V @ 3.7A typical
Power
requirements
+5V @ 2.5A maximum
+5V @ 4.3A maximum
+5V @ 4.2A maximum
+12V @ 0.7A typical
+12V @ 0.75A typical
+12V @ 0.9A typical
+12V @ 2.1A maximum
+12V @ 2.3A maximum
+12V @ 2.3A maximum
100–240 VAC, 50-60 Hz,
auto-ranging, 0.7A maximum
100–240 VAC, 50-60 Hz,
auto-ranging, 0.8A maximum
100–240 VAC, 50-60 Hz,
auto-ranging, 0.8A maximum
Power
requirements,
external
tape
drives
How do I connect the drive to my server?
Installation requires a SAS host controller or host bus adapter (HBA) that supports tape.
NOTE:
All non-HP servers require an additional HBA.
The recommended way of connecting a tape drive to your HP or non-HP SAS server, is to purchase
and install one of the supported HBAs. Always refer to the HP Storage SPOCK website at
BEFORE you install your tape drive to ensure that you are connecting
to a supported HBA running the recommended firmware version. Be sure to check the details of
the specific tape drive and server combination that you require. See
for more information about using SPOCK.
Internal drives
The tape drive is installed into a spare drive bay in your server and is attached to the host server's
internal SAS controller or SAS host bus adapter.
You need one industry-standard, 5¼-inch, half-height bay in which to install the HP LTO Ultrium
tape drive. Different models of server require different mounting methods. Refer to your server
documentation for detailed information. See also
Installing an internal LTO Ultrium tape
.
The cable supplied with the tape drive is suitable for connecting to a mini-SAS (SFF-8086/8087)
connector on a dedicated HBA or on the server's SAS controller. If your server has a SAS 4i
connector (SFF-8484), a suitable cable is available, but must be purchased separately.
NOTE:
Power for the LTO–6 Ultrium 6250 and LTO-5 Ultrium 3000 tape drive is supplied through
the SAS cable. For all earlier models of tape drive, a separate power cable is required, see
Power specifications
7
