M BOX E XTREME ™ M EDIA S ERVER U SER M ANUAL
7 2 02.9800.0001
8 Y Scale 32767 Color2
9 Y Scale
10 Z Scale 32767 Color3
11 Z Scale
12 X Rotation 32767 Beam
13 X Rotation
14 Y Rotation 32767 Edge
15 Y Rotation
16 Z Rotation 32767 Zoom
17 Z Rotation
18 X Spin 127 Shutter
19 Y Spin 127 Prism
20 Z Spin 127 Prism Index
21 Effect 1 0 Effects Wheel
22 Effect Control 1a 0 Effects Index
23 Effect Control 1b 0 Shift-Effects Index
Table B-7: Virtuoso Mbox Extreme Starting Address
Function DMX Address
Light - Ambient 1
Light - Spot 1 5
Light - Spot 2 9
Light - Spot 3 13
Light - Spot 4 17
Camera 21
Shutter 47
Keystone 67
Object 1 89
Object 2 142
Object 3 195
Object 4 248
Object 5 301
Table B-6: Virtuoso Object DMX Mapping (Continued)
Channel Function Default Virtuoso Control
