PRG Mbox EXtreme - Manual (Page 79)

R EFERENCE C HARTS : V IRTUOSO ® C ONSOLE
0 2. 9 8 0 0. 0 0 01 71
B
14 Texture 0 Gobo Wheel
15 Play Mode 0 Shift-Edge
16 Play Speed 127 Edge
17 In Frame 0 Prism
18 In Frame
19 Out Frame 65535 Prism Index
20 Out Frame
21 Aspect 0 Shutter
22 Blending 255 Beam
23 Effect1 0 Rotating Gobo
24 Effect Control 1a 0 Gobo Index
25 Effect Control 1b 0 Shift-Gobo Index
26 Effect 2 0 Effects Wheel
27 Effect Control 2a 0 Effects Index
28 Effect Control 2b 0 Shift-Effects Index
29 XFade Type 0 Misc1
30 XFade Timing 0 Gobo Wheel Timing
Play Modes
0-9 forward loop
10-19 reverse loop
20-29 forward once
30-39 reverse once
40-49 forward bounce
50-59 reverse bounce
60-69 random
70-79 forward once - restart on in
frame change
80-89 scrub - in frame
90-99 scrub - out frame
Table B-6: Virtuoso Object DMX Mapping
Channel Function Default Virtuoso Control
1 Trasparency 0 Intensity
2 Shape Library 0 Shift-Gobo Wheel
3 Shape 0 Gobo Wheel
4 Shape XFade Timing 0 Gobo Wheel Timing
5 Anim Speed 127 Rotating Gobo
6 X Scale 32767 Color1
7 X Scale
Table B-5: Virtuoso Object 2D Channel Mapping (Continued)
Channel Function Default Virtuoso Control
