DMX C HANNEL M APPING : DMX O PERATION
0 2. 9 8 0 0. 0 0 01 53
A
108 Out Frame fine 255
109 Aspect 0 See Aspect Control
110 Blending 255 See Blending Control
111 Effect 1 0 See Texture Effects
112 Effect Control 1a 0
113 Effect Control 1b 0
114 Effect 2 0 See Texture Effects
115 Effect Control 2a 0
116 Effect Control 2b 0
117 XFade Type 0 See Transitions
118 XFade Timing 0
Object 1 - Object
119 Transparency 0
120 Shape Library 0
121 Shape 0 See Built-In Shapes
122 Shape XFade Time 0
123 Anim Speed 127
124 X Scale course 127
125 X Scale fine 255
126 Y Scale course 127
127 Y Scale fine 255
128 Z Scale course 127
129 Z Scale fine 255
130 X Rotation course 127
131 X Rotation fine 255
132 Y Rotation course 127
133 Y Rotation fine 255
134 Z Rotation course 127
135 Z Rotation fine 255
136 X Spin 127
137 Y Spin 127
138 Z Spin 127
139 Effect 1 0
140 Effect Control 1a 0
141 Effect Control 1b 0
Object 2 - Texture
142 Transparency 0
143 X Position course 127
144 X Position fine 255
145 Y Position course 127
146 Y Position fine 255
147 Red 255
148 Green 255
Table A-1: Mbox Extreme Combined DMX Channel Map (Continued)
