DMX C HANNEL M APPING : DMX O PERATION
0 2. 9 8 0 0. 0 0 01 55
A
191 Z Spin 127
192 Effect 1 0
193 Effect Control 1a 0
194 Effect Control 1b 0
Object 3- Texture
195 Transparency 0
196 X Position course 127
197 X Position fine 255
198 Y Position course 127
199 Y Position fine 255
200 Red 255
201 Green 255
202 Blue 255
203 Z Position course 127
204 Z Position fine 255
205 Scale course 127
206 Scale fine 255
207 Library 0
208 Texture 0
209 Play Mode 0 See Play Modes
210 Play Speed 127
211 In Frame course 0
212 In Frame fine
213 Out Frame course 255
214 Out Frame fine 255
215 Aspect 0 See Aspect Control
216 Blending 255 See Blending Control
217 Effect 1 0 See Texture Effects
218 Effect Control 1a 0
219 Effect Control 1b 0
220 Effect 2 0 See Texture Effects
221 Effect Control 2a 0
222 Effect Control 2b 0
223 XFade Type 0 See Transitions
224 XFade Timing 0
Object 3 - Object
225 Transparency 0
226 Shape Library 0
227 Shape 0 See Built-In Shapes
228 Shape XFade Time 0
229 Anim Speed 127
230 X Scale course 127
231 X Scale fine 255
Table A-1: Mbox Extreme Combined DMX Channel Map (Continued)
