R EFERENCE C HARTS : V IRTUOSO ® C ONSOLE
0 2. 9 8 0 0. 0 0 01 69
B
30-39 FPS Display
40-49 Lights/Camera/Shutter/Key-
stone HUD
50-59 Objects HUD
200 DEBUG ONLY: Trace Dump
240 Rescan Media Library
241 Enable SDI output controls
250 Quit Application
251 Shutdown Computer
252 Restart Computer
253 Restart Application
Table B-3: Virtuoso Shutter Channel Mapping
Channel Function Default Virtuoso Control
1 Shape 255 Intensity
2 Shutter X 32767 Pan
3 Shutter X
4 Shutter Y 32767 Tilt
5 Shutter Y
6 Red 0 Color3
7 Green 0 Color2
8 Blue 0 Color1
9 Shutter Scale 32767 Zoom
10 Shutter Scale
11 Shutter Edge 0 Edge
12 Shutter 1a 0 Framing
13 Shutter 1b 0 Framing
14 Shutter 2a 0 Framing
15 Shutter 2b 0 Framing
16 Shutter 3a 0 Framing
17 Shutter 3b 0 Framing
18 Shutter 4a 0 Framing
19 Shutter 4b 0 Framing
20 Shutter Rotation 127 Framing
Table B-2: Virtuoso Camera Channel Map (Continued)
Channel Function Default Virtuoso Control
