DMX C HANNEL M APPING : DMX O PERATION
0 2. 9 8 0 0. 0 0 01 57
A
274 Effect Control 2a 0
275 Effect Control 2b 0
276 XFade Type 0 See Transitions
277 XFade Timing 0
Object 4- Object
278 Transparency 0
279 Shape Library 0
280 Shape 0 See Built-In Shapes
281 Shape XFade Time 0
282 Anim Speed 127
283 X Scale course 127
284 X Scale fine 255
285 Y Scale course 127
286 Y Scale fine 255
287 Z Scale course 127
288 Z Scale fine 255
289 X Rotation course 127
290 X Rotation fine 255
291 Y Rotation course 127
292 Y Rotation fine 255
293 Z Rotation course 127
294 Z Rotation fine 255
295 X Spin 127
296 Y Spin 127
297 Z Spin 127
298 Effect 1 0
299 Effect Control 1a 0
300 Effect Control 1b 0
Object 5- Texture
301 Transparency 0
302 X Position course 127
303 X Position fine 255
304 Y Position course 127
305 Y Position fine 255
306 Red 255
307 Green 255
308 Blue 255
309 Z Position course 127
310 Z Position fine 255
311 Scale course 127
312 Scale fine 255
313 Library 0
314 Texture 0
Table A-1: Mbox Extreme Combined DMX Channel Map (Continued)
