O VERVIEW : C OMPONENTS
0 2. 9 8 0 0. 0 0 01 7
1
Figure 1-2: Case Components / Rear View
Ethernet Card - provides additional
network card for optional connection to
local computer network.
Video Output - DVI / VGA connection
supplies video to front I/O panel.
Dimmer Control - USB connection
provides local Dimmer Control to front
I/O panel.
Keyboard / Mouse Output - USB
connection for keyboard and mouse
devices.
Built-In Ethernet Connection -
provides network connection to front I/O
panel.
Power Supply - provides AC power
to the Apple® Macintosh® G5
computer.
out
in
optical audio
Video Input - optional card for
connecting live video source.
Dongle - used by the application to set
up the correct monitor configuration.
