Theory of Operation
Data Flow Diagrams
DMX512 Input Configuration:
Single Media Server with DMX512 Devices
In the following configuration, DMX512 control signal is distributed from one DMX512 console to
multiple DMX512 devices and one Mbox Extreme Media Server. Data is then distributed from the
Mbox Extreme Media Server to the other components as shown below.
Figure 1-3: Single Media Server with DMX512 Devices
DMX CONSOLE
LOCAL DISPLAY
PROJECTOR
MBOX EXTREME
DMX IN
VIDEO OUT
VIDEO OUT
POWER OUT
RGBHV
