6.7.11
FMDHR, FMDLR, FMRDH, and FMRDL
Transfer contents between an ARM register and a half of a double-precision
floating-point register.
Syntax
FMDHR{cond} Dn, Rd
FMDLR{cond} Dn, Rd
FMRDH{cond} Rd, Dn
FMRDL{cond} Rd, Dn
where:
cond
is an optional condition code (see VFP and condition codes on page 6-8).
Dn
is the VFP double-precision register.
Rd
is the ARM register.
Rd
must not be r15.
Usage
These instructions are used together as matched pairs:
•
Use
FMDHR
with
FMDLR
FMDHR
copy the contents of
Rd
into the high half of
Dn
FMDLR
copy the contents of
Rd
into the low half of
Dn
•
Use
FMRDH
with
FMRDL
FMRDH
copy the contents of the high half of
Dn
into
Rd
FMRDL
copy the contents of the low half of
Dn
into
Rd
.
Exceptions
These instructions do not produce any exceptions.
Examples
FMDHR d5, r3
FMDLR d5, r12
FMRDH r5, d3
FMRDL r9, d3
FMDLRPL d2, r1
