ARM Instruction Reference
4-4
Copyright © 2000, 2001 ARM Limited. All rights reserved.
ARM DUI 0068B
4.1
Conditional execution
Almost all ARM instructions can include an optional condition code. This is shown in
syntax descriptions as
{cond}
. An instruction with a condition code is only executed if
the condition code flags in the CPSR meet the specified condition. The condition codes
that you can use are shown in Table 4-2.
Almost all ARM data processing instructions can optionally update the condition code
flags according to the result. To make an instruction update the flags, include the
S
suffix
as shown in the syntax description for the instruction.
Some instructions (
CMP
,
CMN
,
TST
and
TEQ
) do not require the
S
suffix. Their only function
is to update the flags. They always update the flags.
Flags are preserved until updated. A conditional instruction which is not executed has
no effect on the flags.
Table 4-2 ARM condition codes
Suffix
Flags
Meaning
EQ
Z
set
Equal
NE
Z
clear
Not equal
CS/HS
C
set
Higher or same (unsigned >= )
CC/LO
C
clear
Lower (unsigned < )
MI
N
set
Negative
PL
N
clear
Positive or zero
VS
V
set
Overflow
VC
V
clear
No overflow
HI
C
set and
Z
clear
Higher (unsigned <= )
LS
C
clear or
Z
set
Lower or same (unsigned <= )
GE
N
and
V
the same
Signed >=
LT
N
and
V
different
Signed <
GT
Z
clear, and
N
and
V
the same
Signed >
LE
Z
set, or
N
and
V
different
Signed <=
AL
Any
Always (usually omitted)
